Omron CS1G-CPU42H Replacement Guide From C200H To Cs

9
< I/O Units and CPU Bus Units>
Unit name
C200H-series Unit
CS1-series Unit
Description
Basic I/O Unit
C200H-I□□□
C200H-O□□□
C200H-M□□□
C200H-I□□□
C200H-O□□□
C200H-M□□□
or
CS1W-I□□□
CS1W-O□□□
CS1W-M□□□
C200H-series Basic I/O Units can be used
with CS1-series CPU Units.
Refer to Appendix E. Table of Input/Output
Units for CS1-series Basic I/O Units
corresponding to C200H-series Basic I/O
Units.
To facilitate maintenance, we recommend
you to use CS-series Basic I/O Units
instead.
Special I/O Unit
C200H-□□□□
C200H-□□□□
or
CS1W-□□□□
C200H-series Special I/O Units can be used
with CS1-series CPU Units. However, there
are some remarks to be followed.
To improve the system performance and to
facilitate maintenance, we recommend you
to use the CS-series Special I/O Units
instead.
Communication Unit
[SYSMAC LINK]
Coaxial:
C200H-SLK21-V1
C200HS-SLK22
C200HW-SLK23/24
Optical:
C200H-SLK11
C200HS-SLK12
C200HW-SLK13/14
[SYSMAC LINK]
Coaxial: CS1W-SLK21
Optical: CS1W-SLK11
or
[Controller Link]
Wired: CS1W-CLK23
Optical: CS1W-CLK13/53
C200HW-SLK□□ cannot be used with the
CS1-series CPU Unit.
Refer to the SYSMAC CS1W-SLK11/21
SYSMAC LINK Units OPERATION MANUAL
(Cat. No. W367) for details about SYSMAC
LINK.
We recommend you to use Controller Link
instead.
Refer to the Controller Link Units Operation
Manual (Cat. No. W309) and Optical Ring
Controller Link Units Operation Manual (Cat.
No. W370) for details.
[SYSMAC NET]
C200H-SNT31
C200HS-SNT32
[SYSMAC NET]
None
[Controller Link]
Wired: CS1W-CLK23
Optical: CS1W-CLK13/53
SYSMAC NET cannot be used with the
CS1-series CPU Unit.
We recommend you to use Controller Link
instead.
Refer to the Controller Link Units Operation
Manual (Cat. No. W309) and Optical Ring
Controller Link Units Operation Manual (Cat.
No. W370) for details.
[Host Link]
[Serial Communications]
C200H-series Host Link Units cannot be
used with the CS1-series CPU Unit.
Refer to the SYSMAC CS/CJ Series Serial
Communications Boards/Units OPERATION
MANUAL (Cat. No. W336) for details.
C200H-LK101-PV1
None
CS1W-SCU21-V1
(+ optical link module)
The CS1 Series does not have an
Optical-type Serial Communications
Board/Unit. Use the wired type instead or
use an external optical link module.
C200H-LK201-V1
CS1W-SCU21-V1
CS1W-SCB21-V1
CS1W-SCB41-V1
Host Link port built in the
CPU Unit
Use one of the left CS1-series Units/Boards.
C200H-LK202-V1
CS1W-SCU31-V1
CS1W-SCB41-V1
Use one of the left CS1-series Units/Boards.
[PC Link]
C200H-LK401
[PC Link]
C200H-LK401
[Controller Link]
Wired: CS1W-CLK23
Optical: CS1W-CLK13/53
The PC Link Unit can be used with the
CS1-series CPU Unit. However, the Link
Area allocation must be changed.
We recommend you to use Controller Link
instead.
Refer to the Controller Link Units Operation
Manual (Cat. No. W309) and Optical Ring
Controller Link Units Operation Manual (Cat.
No. W370) for details.
