Generating Virtual External Inputs Section 8-3

161

Read IOM area

MR SR PM FINS Command Replay possible

01 01 30 Read CIO Area bits Not possible

01 01 31 Read Work Area bits Not possible

01 01 32 Read Hold Area bits Not possible

01 01 33 Read Auxiliary Area bits Not possible

01 01 B0 Read CIO Area words Not possible

01 01 B1 Read Work Area words Not possible

01 01 B2 Read Hold Area words Not possible

01 01 B3 Read Auxiliary Area words Not possible

01 01 09 Read Timer/Counter Completion Flag Not possible

01 01 89 Read Timer/Counter PV Not possible

01 01 02 Read DM bits Not possible

01 01 82 Read DM words Not possible

01 01 2 Read EM bits (common) Not possible

01 01 A Read EM words (common) Not possible

01 01 98 Read EM words (current bank) Not possible

01 01 BC Current EM Bank No. Not possible

01 01 06 Read task flag bit Not possible

01 01 46 Read task flag status Not possible

01 01 DC Read Index Register PV Not possible

01 01 BC Read Data Register PV Not possible

01 01 07 Read Clock/Condition bit Not possible

Write IOM area

MR SR PM FINS Command Replay possible

01 02 30 Write CIO Area bits Possible

01 02 31 Write Work Area bits Possible

01 02 32 Write Hold Area bits Possible

01 02 33 Write Auxiliary Area bits Possible

01 02 B0 Write CIO Area words Possible

01 02 B1 Write Work Area words Possible

01 02 B2 Write Hold Area words Possible

01 02 B3 Write Auxiliary Area words Possible

01 02 89 Write Timer/Counter PV Possible

01 02 02 Write DM bits Possible

01 02 82 Write DM words Possible

01 02 2 Write EM bits (common) Possible

01 02 A Write EM words (common) Possible

01 02 98 Write EM words (current bank) Possible

01 02 BC Current EM Bank No. Possible

01 02 DC Write Index Register PV Possible

01 02 BC Write Data Register PV Possible

MR: Main, SR: Sub, PM: Parameter

Note If Replay is not possible, the I/O memory areas do not change although

send/receive of data is executed when Replay.
