Omron CS1G-CPU42H User Manual

I/O Memory Allocation Section 9-3
225
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A50812 Trace
Completed
Flag
ON when sampling of a region of
trace memory has been com-
pleted during execution of a
Trace.
OFF when the next time the
Sampling Start Bit (A50815) is
turned from OFF to ON.
1: Trace
completed
0: Not
tracing or
trace in
progress
Same as
CS/CJ-series
PLC.
A50813 Trace Busy
Flag
ON when the Sampling Start Bit
(A50815) is turned from OFF to
ON. OFF when the trace is com-
pleted.
1: Trace in
progress
0: Not
tracing (not
sampling)
Same as
CS/CJ-series
PLC.
A50814 Trace Start
Bit
Turn this bit from OFF to ON to
establish the trigger condition.
The offset indicated by the delay
value (positive or negative) de-
termines which data samples are
valid.
1: Trace
trigger con-
dition es-
tablished
0: Not es-
tablished
Same as
CS/CJ-series
PLC.
A508
A50815 Sampling
Start Bit
When a data trace is started by
turning this bit from OFF to ON
from a Programming Device, the
PLC will begin storing data Trace
Memory by one of the three fol-
lowing methods:
1) Data is sampled at regular
intervals (10 to 2,550 ms).
2) Data is sampled when
TRSM(045) is executed in the
program.
3) Data is sampled at the end of
every cycle.
0 to 1:
Starts data
trace (sam-
pling)
Same as
CS/CJ-series
PLC.
A509 A50900 SYSMAC
BUS Slave
Number
Refresh Bit
Turn this bit ON to refresh the
error information in A425 (unit
number of Slave where error
occurred after startup).
Not used.
A510 to
A511
Start-up
Time
These words contain the time at
which the power was turned ON.
The contents are updated every
time that the power is turned ON.
The data is stored in BCD.
A51000 to A51007:
Second (00 to 59)
A51008 to A51015:
Minute (00 to 59)
A51100 to A51107:
Hour (00 to 23)
A51108 to A51115:
Day of month (00 to 31)
See Func-
tion col-
umn.
Same as
CS/CJ-series
PLC.
