Omron D4N Series User Manual

D4N
Specifications
Standards and EC Directives
Conforms to the following EC Directives:
x Machinery Directive
x Low Voltage Directive
x EN50047
x EN60204-1
x EN1088
x GS-ET-15
Certified Standards
*1.Consult your OMRON representative for details.
*2.Certification for CSA C22.2 No. 14 is authorized by the UL mark.
*3.Ask your OMRON representative for information on certified
models.
Certified Standard Ratings
TÜV (EN60947-5-1), CCC (GB14048.5)
Note: Use a 10 A fuse type gI or gG that conforms to IEC269 as a
short-circuit protection device. This fuse is not built into the
Switch.
UL/CSA (UL508, CSA C22.2 No. 14)
A300
Q300
Certification
body
Standard File No.
TÜV Product
Service
EN60947-5-1
(certified direct opening)
*1
UL *2 UL508, CSA C22.2 No.14 E76675
CQC (CCC) *3 GB14048.5
2004010305105973
Item
Utilization
category
AC-15 DC-13
Rated operating current (Ie) 3 A 0.27 A
Rated operating voltage (Ue) 240 V 250 V
Rated
voltage
Carry current
Current (A) Volt-amperes (VA)
Make Break Make Break
120 VAC
10 A
60 6
7,200 720
240 VAC 30 3
Rated
voltage
Carry current
Current (A) Volt-amperes (VA)
Make Break Make Break
125 VDC
2.5 A
0.55 0.55
69 69
250 VDC 0.27 0.27
http://www.ia.omron.com/
5
(c)Copyright OMRON Corporation 2007 All Rights Reserved.

Omron D4N Series Specifications

General

Voltage Rating	250 VAC, 30 VDC
Ingress Protection	IP67
Actuator Type	Plunger
Current Rating	10 A
Housing Material	Plastic
Category	Switch
Connection Method	Screw terminals
Operating Speed	0.05 mm/s to 0.5 m/s
Standards	UL 508
Mechanical Life	15, 000, 000 operations minimum
Electrical Life	500, 000 operations
Contact Configuration	1NC/1NO, 2NC
