Omron D4NL-4AFA-B4 - Page 3

3D4NL
Plastic Bottom Special
release
key
Solenoid: 24 VDC
Orange LED: 10 to 115
VAC/VDC
Mechanical lock
Solenoid release
1NC/1NO+1NC/1NO Pg13.5 D4NL-1AFA-B4
G1/2
D4NL-2AFA-B4
M20
D4NL-4AFA-B4
1NC/1NO+2NC Pg13.5
D4NL-1BFA-B4
G1/2
D4NL-2BFA-B4
M20
D4NL-4BFA-B4
2NC+1NC/1NO Pg13.5
D4NL-1CFA-B4
G1/2
D4NL-2CFA-B4
M20
D4NL-4CFA-B4
2NC+2NC Pg13.5
D4NL-1DFA-B4
G1/2
D4NL-2DFA-B4
M20
D4NL-4DFA-B4
2NC/1NO+1NC/1NO Pg13.5
D4NL-1EFA-B4
G1/2
D4NL-2EFA-B4
M20
D4NL-4EFA-B4
2NC/1NO+2NC Pg13.5
D4NL-1FFA-B4
G1/2
D4NL-2FFA-B4
M20
D4NL-4FFA-B4
3NC+1NC/1NO Pg13.5
D4NL-1GFA-B4
G1/2
D4NL-2GFA-B4
M20
D4NL-4GFA-B4
3NC+2NC Pg13.5
D4NL-1HFA-B4
G1/2
D4NL-2HFA-B4
M20
D4NL-4HFA-B4
Solenoid lock
Mechanical release
1NC/1NO+1NC/1NO Pg13.5
D4NL-1AFG-B4
G1/2
D4NL-2AFG-B4
M20
D4NL-4AFG-B4
1NC/1NO+2NC Pg13.5
D4NL-1BFG-B4
G1/2
D4NL-2BFG-B4
M20
D4NL-4BFG-B4
2NC+1NC/1NO Pg13.5
D4NL-1CFG-B4
G1/2
D4NL-2CFG-B4
M20
D4NL-4CFG-B4
2NC+2NC Pg13.5
D4NL-1DFG-B4
G1/2
D4NL-2DFG-B4
M20
D4NL-4DFG-B4
2NC/1NO+1NC/1NO Pg13.5
D4NL-1EFG-B4
G1/2
D4NL-2EFG-B4
M20
D4NL-4EFG-B4
2NC/1NO+2NC Pg13.5
D4NL-1FFG-B4
G1/2
D4NL-2FFG-B4
M20
D4NL-4FFG-B4
3NC+1NC/1NO Pg13.5
D4NL-1GFG-B4
G1/2
D4NL-2GFG-B4
M20
D4NL-4GFG-B4
3NC+2NC Pg13.5
D4NL-1HFG-B4
G1/2
D4NL-2HFG-B4
M20
D4NL-4HFG-B4
Head
material
Release
key
position
Release
key type
Solenoid voltage/
indicator
Lock and release types Contact configuration
(door open/closed
detection switch and lock
monitor switch contacts)
(slow-action)
Approved direct opening
NC contact
Conduit opening Model
