8
E3NC
Ultra-compact CMOS Laser Sensor: E3NC-S
Sensor Heads
Note: Incorrect detection may occur outside the measurement range if the object has a high reflection factor.
*1. These Sensors are classified as Class 1 laser devices under IEC 60825-1 and the regulations of Laser Notice No. 50 for FDA certification. CDRH (Center for De-
vices and Radiological Health) registration has been completed. (Accession Number: 1220691)
*2. The values were measured at the center of the sensing distance using OMRON’s standard sensing object (white ceramic).
*3. Beam size: Defined at the 1/e
2
(13.5 %) of the central intensity at the measurement center distance.
Measurement may be influenced if there is light leakage outside the defined region and the surroundings of the target object have a high reflectance in comparison
to the target object.
Also, when detecting a workpiece that is smaller than the beam size, a correct value may not be obtained.
Sensing method Distance-settable
Item Model E3NC-SH250H E3NC-SH250 E3NC-SH100
Light source (wavelength)*1
Visible semiconductor laser
diode (660 nm), 1 mW (average
output: 220 μW) (JIS Class 2,
IEC/EN Class 2, and FDA Class
2)
Visible semiconductor laser diode (660 nm), 0.5 mW (average
output: 100 μW) (JIS Class 1, IEC/EN Class 1, and FDA Class 1)
Measurement range 35 to 250 mm (display value: 350 to 2,500)
35 to 100 mm (display value: 350
to 1,000)
Standard detected level difference
*2
35 to 180mm: 9 mm
180 to 250 mm: 25 mm
35 to 50 mm: 1.5 mm
50 to 100 mm: 3 mm
Beam size*3 Approx. 1 mm dia. at 250 mm Approx. 0.5 mm dia. at 100 mm
Indicators OUT indicator (orange), STABILITY indicator (green), and ST indicator (blue)
Ambient illumination
(Receiver side)
Incandescent lamp: 4,000 lx
max.,
Sunlight: 8,000 lx max.
Incandescent lamp: 2,000 lx
max.,
Sunlight: 4,000 lx max.
Incandescent lamp: 4,000 lx
max.,
Sunlight: 8,000 lx max.
Ambient temperature range Operating: −10 to 50°C; Storage: −25 to 70°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85% (with no condensation)
Altitude 2,000 m max.
Installation environment Pollution degree 3 (as per IEC 60947-1)
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength 1,000 VAC at 50/60 Hz for 1 min
Vibration resistance (destruction) 10 to 55 Hz with a 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Shock resistance (destruction) 500 m/s
2
3 times each in X, Y, and Z directions
Degree of protection IEC IP67
Connecting method Pre-wired connector (Standard cable length: 2 m)
Materials
Case Polybutylene terephthalate (PBT)
Lens Methacrylic resin (PMMA)
Cable Vinyl chloride (PVC)
Weight (packed state/Sensor Head
only)
Approx. 125 g/approx. 75 g
Accessories Instruction Manual, laser warning label (E3NC-SH250H only)
