16 Oil-resistant, Robust, Compact Photoelectric Sensor E3ZM-C
7.5
25.4
2
31
15.5
20.6
3.5
10.8
32.2
11.6
4.5
21
Receiver
Emitter
Two, M3
Optical
axis
Stability indicator (green)
Operation indicator (yellow)
Sensitivity adjuster
Operation selector
4-dia. vinyl-insulated round cable with
3 conductors (Conductor cross section:
0.2 mm
2
, Insulator diameter: 1.1 mm),
Standard length: 2m
Retro-reflective Models
Pre-wired Models
E3ZM-CR61
E3ZM-CR81
Diffuse-reflective
Models
Pre-wired Models
E3ZM-CD62
E3ZM-CD82
44.7
4
3
2
1
M12×1
M12 Pre-wired Connector
(E3ZM-@@@-M1TJ)
*4-dia. vinyl-insulated round cable
with 3 conductors,
Standard length: 0.3 m
Terminal No. Specifications
1+V
2---
30 V
4Output
7.5
Receiver
Emitter
15.5
20.6
3.5
25.4
2
31
32.2
10.8
11.6
4.5
21
0.7
M8 × 1
Two,
M3
Optical
axis
Stability indicator (green)
Operation indicator (yellow)
Sensitivity adjuster
Operation selector
24
1
3
Retro-reflective Models
Connector Models
E3ZM-CR66
E3ZM-CR86
Diffuse-reflective
Models
Connector Models
E3ZM-CD67
E3ZM-CD87
Terminal No. Specifications
1+V
2---
30 V
4Output
B
GS
Reflective Models
Pre-wired Models
E3ZM-CL61H
E3ZM-CL62H
E3ZM-CL64H
E3ZM-CL81H
E3ZM-CL82H
E3ZM-CL84H
7.5
25.4
31
15.5
20.6
3.5
10.8
32.2
21
Receiver
Emitter
Two, M3
Optical
axis
Stability indicator (green)
Operation indicator (yellow)
4-dia. vinyl-insulated round cable with
4 conductors (Conductor cross section:
0.2 mm
2
, Insulator diameter: 1.1 mm),
Standard length: 2m
Terminal No. Specifications
1+V
2 Operation selection
30 V
4Output
44.7
4
3
2
1
M12×1
M12 Pre-wired Connector
(E3ZM-@@@-M1TJ)
*4-dia. vinyl-insulated round cable
with 3 conductors,
Standard length: 0.3 m
B
GS
Reflective Models
Connector Models
E3ZM-CL66H
E3ZM-CL67H
E3ZM-CL69H
E3ZM-CL86H
E3ZM-CL87H
E3ZM-CL89H
7.5
Receiver
Emitter
15.5
20.6
3.5
25.4
31
32.2
10.8
21
0.7
M8 × 1
Two,
M3
Optical
axis
Stability indicator (green)
Operation indicator (yellow)
24
1
3
Terminal No. Specifications
1+V
2 Operation selection
30 V
4Output
