F3W-D
3
3
Ratings and Specifications
*1. The F3W-D052@P Emitters are provided with the external picking indicator output line shown in the following table.
*2. The transmission indicator indicates bus transmission status.
*3. The following cable lengths are also available.
F3W-D052A (P): 2 m, 7 m
F3W-D052B : 1 m, 3.5 m
Sensing method Through-beam
Item Model F3W-D052A (P) *1 F3W-D052B (P) *1
Sensing distance 3 m, switchable between LONG mode (1 to 3 m) and SHORT mode: (0.05 to 1 m), factory-set to SHORT mode.
Beam gap 25 mm
Number of beams 5
Sensing width 100 mm
Standard sensing object Opaque, 35 mm dia. min.
Light source
(emission wavelength)
Infrared LED (860 nm)
Power supply voltage 12 to 24 VDC±10% (ripple (p-p): 10% max.)
Power consumption Emitter: 0.6 W max., Receiver: 0.7 W max.
Control output
NPN open collector with 100 mA max. at 30 VDC
NPN open collector output type
Dark-ON or Light-ON (selectable)
Picking instruction
indicator input
Open collector with relay or transistor input
Indicator ON: Input voltage of 0 to 2 V
Indicator OFF: Open (with leakage current of 0.1 mA max.)
Protection circuits
Reverse-connection protection, output short protection, and mutual interference prevention function
(set with frequency switch)
Response time Operate/Reset: 10 ms max.
Indicators
Receiver
Operation indicator (orange), stability indicator (green), and 6 picking indicators (orange),
UNI-WIRE Direct Connection Models: Transmission indicator (orange) *2
Emitter
Power indicator (green), different frequency indicator (green), and 6 picking indicators (orange),
UNI-WIRE Direct Connection Models: Transmission indicator (orange) *2
Ambient temperature Operating: −10° to 55°C, Storage: −25° to 70°C (with no icing or condensation)
Ambient humidity 35% to 85% (with no condensation)
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength 1,000 VAC 50/60 Hz for 1 min
Vibration resistance
(destruction)
10 to 50 Hz, 1.5-mm double-amplitude for 2 hours each in X, Y and Z directions
Shock resistance
(destruction)
500 m/s
2
, 3 times each in X, Y and Z directions
Degree of protection IEC60529: IP62 (with the operation cover closed)
Connection method
Pre-wired
Standard cable length: 5 m *3
Pre-wired connector
(M12 5-pin connector)
Standard cable length: 2 m *3
Weight (packed state) Approx. 360 g Approx. 230 g
Materials
Case,
indicator
windows
ABS resin
Lens Acrylic resin
Opera-
tion
cover
Nylon (PA6)
Accessories Instruction manual
Item F3W-D052AP, F3W-D052BP
Connection method Pre-wired (standard cable length: 300 mm)
Electrical specifications
Output current: 50 mA max.
Output voltage: Fixed at Sensor power supply voltage
