F3W-E
9
Dimensions (Unit: mm)
Sensors
F3W-E
<F3W-E032B6/B8-L>
4.2
3.8
8
6.5
3.5
7
6 × 6.5
= 39
24
Two, M4 nut holes
(Depth: 3.2 mm)
Two, 4.5 dia.
50
6.5
63
25
70
Vinyl-insulated round cable
with four conductors, 4 dia.
Conductor: 0.2 mm
2
, Insulation: 1.1-mm dia.
Standard length: 2 m
63
±0.1
Two, M4 holes
Cable length: 0.3 m
44.7
M12
1
4
2
3
14.9 dia.
Emitter
F3W-E032A6/A8-L
F3W-E032B6/B8-L
Mounting Hole Dimensions
<F3W-E032B6/B8-D>
6.5
6.5
3.5
7
6 × 6.5
= 39
24
Two, 4.5 dia.
50 63
25
4.2
3.8
8
70
Vinyl-insulated round cable
with four conductors, 4 dia.
Conductor: 0.2 mm
2
, Insulation: 1.1-mm dia.
Standard length: 2 m
63
±0.1
Two, M4 holes
Cable length: 0.3 m
44.7
M12
1
4
2
3
14.9 dia.
Two, M4 nut holes
(Depth: 3.2 mm)
Mounting Hole Dimensions
Receiver
F3W-E032A6/A8-D
F3W-E032B6/B8-D
