A-132 Standard Photoelectric Sensors
Accessories (Order Separately)
Reflectors and Mounting Brackets
H-3
Terminal Protection Cover for Side-pullout Cable
E39-L129-G
19
22
81.5
29
M2.6
M2.6
61.8
Hexagonal nut
(Diagonal: 22)
Applicable cord: 6 to 8 dia.
90.3
81
44 Cap (Attach to E39-L129-G)
(Conduit)
Note: 1 .The cover is provided with a rubber bushing and cap
to prevent the cable from being pulled out in vertical
direction.
Terminal Protection Cover for Side-pull-
out Cable (Example of E3G-MR19-G)
