4
E3Z-BE3Z-B
Dimensions
Note: All units are in millimeters unless otherwise indicated.
■
Sensors
Retroreflective Models (Pre-wired Models)
Accessories (Ordered Separately)
Retroreflective Models (Connector Models)
Precautions
Be sure to abide by the following precautions for the safe operation of the Sensor.
For wiring precautions, refer to Precautions in Cat. No. E308-E1.
■
Correct Use
Design
Bottles
The Sensor may be unable to achieve stable detection depending
on the shape of bottles. Be sure to verify stable detection before
using the Sensor.
Mounting
Sensor Mounting
If the Sensor fails to provide stable detection due to the shape of
bottles, adjust the location and inclination of the Sensor.
20
12.45
8.8
3.2
Stability indicator (green)
Operation indicator (orange)
17
2.1
25.4
4-dia., 3-core vinyl-insulated round cable
(Conductor cross-section: 0.2 mm
2
; Insulator diameter: 1.1 mm
Standard length: 2 m
Two, M3
31
15.5
2 lenses (7 dia.)
Receiver
Optical axis
Emitter
4＊
18
4＊
10.410.8
4.3
Sensitivity adjuster
Mode selector
* 3.75 for E3Z-B
@
2
Two, 3.5 dia.
Coating on surface
(for E39-R1K only)
Material
Surface: Acrylic resin
Backside: ABS resin
Reflectors
E39-R1S
E39-R1K
20
12.45
8.8
3.2
Stability indicator (green)
Operation indicator (orange)
17
2.1
25.4
M8 connector
31
10.4
15.5
2 lenses (7 dia.)
Receiver
Optical axis
Emitter
4＊
18
4＊
10.410.8
4.3
Sensitivity adjuster
Mode selector
9.75
2-M3
* 3.75 for E3Z-B
@
7
In the interest of product improvement, specifications are subject to change without notice.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.
Cat. No. E316-E1-1
OMRON Corporation
Industrial Automation Company
Industrial Devices and Components Division H.Q.
Industrial Control Components Department
Shiokoji Horikawa, Shimogyo-ku
Kyoto, 600-8530 Japan
Tel: (81)75-344-7119/Fax: (81)75-344-7149
Printed in Japan
0301-1M (0301) (A)
