Omron E3ZM-V81 - Series Overview and Specifications; E3 ZM Standard Models; BGS Reflective and PET Bottle Models

E3ZM-V
14
Introducing the E3ZM Series
E3ZM Standard Models (E3ZM-T/-R/-D/-LS) Ideal for the Food Industry, and Models for PET Bottle Detection (E3ZM-B).
Ratings and Specifications
* Values in brackets are the minimum required distance between the Sensor and Reflector.
Sensing method Through-beam
Retro-reflective with MSR
function
Diffuse-reflective Models
Model NPN output
E3ZM-T61
E3ZM-T66
E3ZM-T63
E3ZM-T68
E3ZM-R61
E3ZM-R66
E3ZM-D62
E3ZM-D67
Item PNP output
E3ZM-T81
E3ZM-T86
E3ZM-T83
E3ZM-T88
E3ZM-R81
E3ZM-R86
E3ZM-D82
E3ZM-D87
Sensing distance 15 m 0.8 m
4 m [100 mm] * (Using E39-R1S)
3 m [100 mm] * (Using E39-R1)
1 m
(White paper 300 ✕ 300 mm)
Spot diameter ---
Standard sensing object Opaque: 12-mm dia. min. Opaque: 2-mm dia. min. Opaque: 75-mm dia. min. ---
Differential travel --- 20% of sensing distance max.
Reflectivity characteristics
(black/white error)
---
Directional angle Emitter, Receiver: 3° to 15°
Sensor: 3° to 10°
Reflector: 30°
---
Light source (wavelength) Infrared LED (870 nm) Red LED (660 nm) Infrared LED (860 nm)
Power supply voltage 10 to 30 VDC, including 10% ripple (p-p)
Current consumption 40 mA max. (Emitter, Receiver: 20 mA max. each) 25 mA max.
Control output
Load power supply voltage: 30 VDC max., Load current: 100 mA max. (Residual voltage: 2 V max.)
Open-collector output (NPN/PNP output depending on model)
Light-ON/Dark-ON switch selectable
Protection circuits
Reversed power supply polarity protection, Output short-circuit
protection, and Reversed output polarity protection
Reversed power supply polarity protection, Output short-circuit
protection, Mutual interference prevention, and Reversed
output polarity protection
Response time Operate or reset: 1 ms max.
Sensitivity adjustment One-turn adjuster
Ambient illumination (Receiver side) Incandescent lamp: 3,000 lx max., Sunlight: 10,000 lx max.
Ambient temperature range Operating: −25°C to 55°C, Storage: −40°C to 70°C (with no icing or condensation)
Sensing method BGS Reflective Models
Models for PET Bottle Detec-
tion Retro-reflective (P-
opaquing and MSR Function)
Model NPN output
E3ZM-LS61H
E3ZM-LS66H
E3ZM-LS62H
E3ZM-LS67H
E3ZM-LS64H
E3ZM-LS69H
E3ZM-B61
E3ZM-B66
Item PNP output
E3ZM-LS81H
E3ZM-LS86H
E3ZM-LS82H
E3ZM-LS87H
E3ZM-LS84H
E3ZM-LS89H
E3ZM-B81
E3ZM-B86
Sensing distance
10 to 100 mm (White paper
100 ✕ 100 mm)
10 to 150 mm (White paper
100 ✕ 100 mm)
10 to 200 mm (White paper
100 ✕ 100 mm)
100 to 500 mm
(Using E39-RP1)
Spot diameter
4-mm dia. at sensing distance
of 100 mm
12-mm dia. at sensing
distance of 150 mm
18-mm dia. at sensing
distance of 200 mm
---
Standard sensing object ---
Transparent round 500-ml PET
bottles (65 mm dia.)
Differential travel 3% of sensing distance max. 15% of sensing distance max. 20% of sensing distance max. ---
Reflectivity characteristics
(black/white error)
5% of sensing distance max. 10% of sensing distance max. 20% of sensing distance max. ---
Directional angle ---
Sensor: 3
° to 10°
Reflector: 30°
Light source (wavelength) Red LED (650 nm) Red LED (660 nm) Red LED (650 nm)
Power supply voltage 10 to 30 VDC, including 10% ripple (p-p)
Current consumption/
power consumption
25 mA max. 450 mW max.
Control output
Load power supply voltage: 30 VDC max., Load current: 100 mA max. (Residual voltage: 2 V max.)
Open-collector output (NPN/PNP output depending on model)
Light-ON/Dark-ON cable connection selectable
Protection circuits
Reversed power supply polarity protection, Output short-circuit protection, Mutual interference prevention, and Reversed output
polarity protection
Response time Operate or reset: 1 ms max.
Sensitivity adjustment --- Adjusted by teaching
Ambient illumination (Receiver side) Incandescent lamp: 3,000 lx max., Sunlight: 10,000 lx max.
Ambient temperature range Operating: −25°C to 55°C, Storage: −40°C to 70°C (with no icing or condensation)
Operating: −40°C to 60°C,
Storage: −40°C to 70°C (with
no icing or condensation)
