5 - 11
5 Communications Data for Modbus
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
5-1 Variable Area (Setting Range) List
5
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0E28 2E14 Transfer Output Upper
Limit
H'FFFFF831 to H'0000270F (−1999 to 9999)
*1
Initial setting
0E2A 2E15 Transfer Output Lower
Limit
H'FFFFF831 to H'0000270F (−1999 to 9999)
*1
0E48 2E24 Extraction of Square Root
Enable
H'00000000 (0): OFF
H'00000001 (1): ON
0E52 2E29 Travel Time H'00000001 to H'000003E7 (1 to 999)
0E54 2E2A Valve Completely Closed
Position
H'00000000 to H'0000270F (0 to 9999)
0E56 2E2B Valve Completely Open
Position
H'00000000 to H'0000270F (0 to 9999)
0E58 2E2C Potentiometer
Specification Setting
H'00000000 to H'00000005 (0 to 5)
0F00 2F00 Alarm 1 Type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower-limit alarm
H'00000002 (2): Upper-limit alarm
H'00000003 (3): Lower-limit alarm
H'00000004 (4): Upper and lower-limit range alarm
H'00000005 (5): Upper and lower-limit alarm with standby sequence
H'00000006 (6): Upper-limit alarm with standby sequence
H'00000007 (7): Lower-limit alarm with standby sequence
H'00000008 (8): Absolute-value upper-limit alarm
H'00000009 (9): Absolute-value lower-limit alarm
H'0000000A (10): Absolute-value upper-limit alarm with standby
sequence
H'0000000B (11): Absolute-value lower-limit alarm with standby
sequence
H'0000000C (12): LBA (Loop Burnout Alarm)
H'0000000D (13): PV change rate alarm
H'0000000E (14): SP absolute-value upper-limit alarm
H'0000000F (15): SP absolute-value lower-limit alarm
H'00000010 (16): MV absolute-value upper-limit alarm
H'00000011 (17): MV absolute-value lower-limit alarm
0F02 2F01 Alarm 1 Latch H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F04 2F02 Alarm 1 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
Initial setting
0F06 2F03 Alarm 2 Type H'00000000 to H'00000011 (0 to 17)
Note: Same settings as the Alarm 1 Type. However, the LBA (loop
burnout alarm) cannot be set.
0F08 2F04 Alarm 2 Latch H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F0A 2F05 Alarm 2 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
Initial setting
0F0C 2F06 Alarm 3 Type H'00000000 to H'00000011 (0 to 17)
Note: Same settings as the Alarm 1 Type. However, the LBA (loop
burnout alarm) cannot be set.
0F0E 2F07 Alarm 3 Latch H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F10 2F08 Alarm 3 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
Initial setting
0F12 2F09 Alarm 4 Type H'00000000 to H'00000011 (0 to 17)
Note: Same settings as the Alarm 1 Type. However, the LBA (loop
burnout alarm) cannot be set.
*1 The setting (monitor) range depends on the transfer output type setting. Refer to Section 6 Parameters in the E5
@
C-T
Digital Temperature Controller User’s Manual (Cat. No. H185).
To Next Page
