5 Communications Data for Modbus
5 - 12
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
0F14 2F0A Alarm 4 Latch H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
0F16 2F0B Alarm 4 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
Initial setting
0F18 2F0C Standby Sequence Reset H'00000000 (0): Condition A
H'00000001 (1): Condition B
Advanced
function
setting
0F1A 2F0D Auxiliary Output 1 Open
in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F1C 2F0E Auxiliary Output 2 Open
in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
Advanced
function
setting
0F1E 2F0F Auxiliary Output 3 Open
in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F20 2F10 Auxiliary Output 4 Open
in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F22 2F11 Alarm 1 ON delay H'00000000 to H'000003E7 (0 to 999)
0F24 2F12 Alarm 2 ON delay H'00000000 to H'000003E7 (0 to 999)
0F26 2F13 Alarm 3 ON delay H'00000000 to H'000003E7 (0 to 999)
0F28 2F14 Alarm 4 ON delay H'00000000 to H'000003E7 (0 to 999)
0F2A 2F15 Alarm 1 OFF delay H'00000000 to H'000003E7 (0 to 999)
0F2C 2F16 Alarm 2 OFF delay H'00000000 to H'000003E7 (0 to 999)
0F2E 2F17 Alarm 3 OFF delay H'00000000 to H'000003E7 (0 to 999)
0F30 2F18 Alarm 4 OFF delay H'00000000 to H'000003E7 (0 to 999)
1000 3000 PV/SP No. 1 Display
Selection
H'000000000 (0): Nothing displayed.
H'000000001 (1): PV/SP
H'000000002 (2): PV
H'000000003 (3): SP/SP (character display)/Nothing displayed
H'000000004 (4): PV/SP/MV (heating) (valve opening for
Position-proportional Models)
H'000000005 (5): PV/SP/MV (cooling)
H'000000006 (6): PV/SP/Program No. or segment No.
H'000000007 (7): PV/SP/Remaining segment time
1006 3003 Automatic Display Return
Time
H'00000000 (0): OFF
H'00000001 to H'00000063 (1 to 99)
1008 3004 Display Refresh Period H'00000000 (0):OFF
H'00000001 (1): 0.25
H'00000002 (2): 0.5
H'00000003 (3): 1.0
1010 3008 PV/SP No. 2 Display
Selection
H'00000000 to H'00000007 (0 to 7)
Note: Same as PV/SP No. 1 Display Selection.
1014 300A Display Brightness H'00000001 to H'00000003 (1 to 3)
1018 300C Move to Protect Level
Time
H'00000001 to H'0000001E (1 to 30)
1022 3011 PV Status Display
Function
H'00000000 (0): OFF
H'00000001 (1): Manual
H'00000002 (2): RESET
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 4
H'00000007 (7): Alarm 1 to 4 OR status
H'00000008 (8): Heater alarm
H'00000009 (9): Standby
1024 3012 SV Status Display
Function
H'00000000 to H'00000009 (0 to 9)
Note: Same as for PV Status Display Function.
