5 Communications Data for Modbus
5 - 14
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
1200 3200 PF Setting H'00000000 (0): Disabled
H'00000001 (1): Run
H'00000002 (2): RESET
H'00000003 (3): RUN/RESET
H'00000004 (4): Hold/clear hold
H'00000005 (5): Advance
H'00000006 (6): 100% AT execute/cancel
H'00000007 (7): 40% AT execute/cancel
H'00000008 (8): All PID 100% AT execute/cancel
H'00000009 (9): All PID 40% AT execute/cancel
H'0000000A (10): Alarm latch cancel
H'0000000B (11): Auto/manual switch
H'0000000C (12): Monitor/setting item
H'0000000D (13): Digit shift key
Advanced
function
setting
1204 3202 Monitor/Setting Item 1 H'000000000 (0): Disabled
H'000000001 (1): PV/SP/Program No. monitor or segment No.
monitor
H'000000002 (2): PV/SP/MV (heating) (valve opening for
Position-proportional Models)
H'000000003 (3): PV/SP/MV (cooling)
H'000000004 (4): PV/SP/Remaining segment time
H'000000005 (5): Program No.
H'000000006 (6): Segment No. monitor
H'000000007 (7): Remaining standby time monitor
H'000000008 (8): Elapsed program time monitor
H'000000009(9): Remaining program time monitor
H'00000000A (10): Elapsed segment time monitor
H'00000000B (11): Remaining segment time monitor
H'00000000C (12): Program execution repetitions monitor
H'00000000D (13): Proportional band
H'00000000E (14): Integral time
H'00000000F (15): Derivative time
H'000000010 (16): Proportional band (cooling)
H'000000011 (17): Integral time (cooling)
H'000000012 (18): Derivative time (cooling)
H'000000013 (19): Alarm value 1
H'000000014 (20): Alarm value upper limit 1
H'000000015 (21): Alarm value lower limit 1
H'000000016 (22): Alarm value 2
H'000000017 (23): Alarm value upper limit 2
H'000000018 (24): Alarm value lower limit 2
H'000000019 (25): Alarm value 3
H'00000001A (26): Alarm value upper limit 3
H'00000001B (27): Alarm value lower limit 3
H'00000001C (28): Alarm value 4
H'00000001D (29): Alarm value upper limit 4
H'00000001E (30): Alarm value lower limit 4
1206 3203 Monitor/Setting Item 2 H'00000000 to H'0000001E (0 to 30)
Note: Same as for Monitor/Setting Item 1.
1208 3204 Monitor/Setting Item 3 H'00000000 to H'0000001E (0 to 30)
Note: Same as for Monitor/Setting Item 1.
120A 3205 Monitor/Setting Item 4 H'00000000 to H'0000001E (0 to 30)
Note: Same as for Monitor/Setting Item 1.
120C 3206 Monitor/Setting Item 5 H'00000000 to H'0000001E (0 to 30)
Note: Same as for Monitor/Setting Item 1.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
