5-1 Variable Area (Setting Range) List
5
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
1300 3300 Startup Operation H'00000000 (0): Continue control at final SP
H'00000001 (1): RESET
H'00000002 (2): RUN
H'00000003 (3): Manual
*1
Initial setting
1302 3301 SP Tracking H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
1304 3302 PID Set Automatic
Selection Data
H'00000000 (0): PV
H'00000001 (1): DV
H'00000002 (2): SP
1306 3303 PID Set Automatic
Selection Hysteresis
H'0000000A to H'0000270F (0.10 to 99.99)
1308 3304 PV Dead Band H'00000000 to H'0000270F (0 to 9999)
130A 3305 Cold Junction
Compensation Method
H'00000000 (0): OFF
H'00000001 (1): ON
1312 3309 Integral/Derivative Time
Unit
H'00000000 (0): 1 s
H'00000001 (1): 0.1 s
1314 330A α H'00000000 to H'00000064 (0.00 to 1.00)
1318 330C Manual Output Method H'00000000 (0): HOLD
H'00000001 (1): INIT
131A 330D Manual MV Initial Value Standard control or close position-proportional control:
H'FFFFFFCE to H'0000041A (−5.0 to 105.0)
Heating and cooling control:
H'FFFFFBE6 to H'0000041A (−105.0 to 105.0)
131E 330F AT Calculated Gain H'00000001 to H'00000064 (0.1 to 10.0)
1320 3310 AT Hysteresis H'00000001 to H'0000270F (0.1 to 999.9 for temperature input)
H'00000001 to H'000003E7 (0.01 to 9.99 for analog input)
1322 3311 Limit Cycle MV Amplitude H'00000032 to H'000001F4 (5.0 to 50.0)
1328 3314 Heater Burnout Latch H'00000000 (0): OFF
H'00000001 (1): ON
132A 3315 Heater Burnout
Hysteresis
H'00000001 to H'000001F4 (0.1 to 50.0)
132C 3316 HS Alarm Latch H'00000000 (0): OFF
H'00000001 (1): ON
132E 3317 HS Alarm Hysteresis H'00000001 to H'000001F4 (0.1 to 50.0)
1334 331A Operation End Operation H'00000000 (0): RESET
H'00000001 (1): Continue control at final SP
H'00000002 (2): Fixed SP mode
*2
Initial setting
1338 331C HB ON/OFF H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
function
setting
133A 331D Program End ON Time H'00000000 to H'00000064 (0.0 to 10.0)
H'FFFFFFFF (−1): ON
133C 331E Integrated Alarm
Assignment
H'00000000 to H'000000FF (0 to 255)
1344 3322 RT H'00000000 (0): OFF
H'00000001 (1): ON
Note: Valid only with temperature input.
1346 3323 HS Alarm Use H'00000000 (0): OFF
H'00000001 (1): ON
1348 3324 LBA Detection Time H'00000000 to H'0000270F (0 to 9999)
134A 3325 LBA Level H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
134C 3326 LBA Band H'00000000 to H'0000270F
(0.0 to 999.9 for temperature input)
(0.00 to 99.99 for analog input)
*1 Selection is not possible when ON/OFF control is set.
*2 Selection is not possible if the Reset Operation parameter is set to fixed SP operation.
