Omron E5AN Communications Manual

CompoWay/F
2.3 Detailed Description of the Services
2-11
(3) Number of Elements
(4) Response Code
Normal Completion
Error Occurred
Number of elements Processing
0000 The write operation is not performed (do
not append write data to the service
request PDU) and processing ends in
“normal completion.”
Double word
(variable type C0,
C1, or C3)
0001 to 0018
(1 to 24)
The write operation is performed and
processing ends in a normal comple-
tion.
Word (variable
type 80, 81, or 83)
0001 to 0030
(1 to 48)
Response code Name Description
0000 Normal completion No errors were found.
Response code Error name Cause
1002 Command too
short
The command is too short.
1101 Area type error The variable type is wrong.
1103 Start address out-
of-range error
Write start address is out of range.
1104 End address out-
of-range error
The write end address (write start
address + number of elements)
exceeds the final address of the vari-
able area.
1003 Number of ele-
ments/data mis-
match
The number of data does not match
the number of elements.
1100 Parameter error • Bit position is not “00.”
• The write data is out of the setting
range.
3003 Read-only error Variable type “C0” was written to.
2203 Operation error • The Communications Writing
parameter is set to “OFF” (dis-
abled).
• Attempted to write to a parameter
in setup area 1 from setup area 0.
• Attempted to write to a protect
parameter from other than the pro-
tect level.
• AT (auto-tuning) was in progress.
(See note.)
• EEPROM error
