CompoWay/F
2.3 Detailed Description of the Services
2-13
Note: The following table gives the maximum number of read data items
when double-word data and word data are used together.
(4) Response Code
Normal Completion
Error Occurred
Composite Write to Variable Area
This service writes in order the contents of specified addresses to a
variable area.
Composite Read Composite Read
Double word
(variable type C0, C1, or
C3)
Word
(variable type 80, 81, or
83)
Double word
(variable type C0, C1, or
C3)
Word
(variable type 80, 81, or
83)
20 0 11 14
19 1 10 15
18 2 9 16
18 3 8 17
17 4 7 18
17 5 6 19
16 6 5 20
15 7 4 21
15 8 3 22
14 9 2 23
14 10 1 24
13 11 0 25
12 12
12 13
Response code Name Description
0000 Normal completion No errors were found.
Response code Error name Cause
1002 Command too short The command is too
short.
1101 Area type error The variable type is
wrong.
110B Response too long The number of elements
exceeds the maximum.
1100 Parameter error Bit position is not “00.
2203 Operation error EEPROM error
