Com Data for

CompoWay/F

3.1 Variable Area (Setting Range) List

3-11

Note 1: After communications parameters have been changed, reset the Controller to enable them.

Note 2: P.END (program end output) can be set even when the program pattern is set to OFF, but the

function will be disabled.

Note 3: The output turns ON when the status of either the Control Output 1 ON/OFF Count Alarm or the

Control Output 2 ON/OFF Count Alarm turns ON.

Vari-

able

type

Ad-

dress

Parameter name Setting (monitor) value Level

C3 (83) 004C Protocol Setting (See

note 1.)

H'00000000 (0): CompoWay/F (SYSWAY)

H'00000001 (1): Modbus

Commu-

nications

setting

C3 (83) 004D Send Data Wait Time

(See note 1.)

H'00000000 to H'00000063 (0 to 99)

C3 (83) 004E Control Output 1 Assign-

ment

When control output 1 is a linear output:

H'00000000 (0): Not assigned.

H'00000001 (1): Control output (heating)

H'00000002 (2): Control output (cooling)

When control output 1 is an ON/OFF output:

H'00000000 (0): Not assigned.

H'00000001 (1): Control output (heating)

H'00000002 (2): Control output (cooling)

H'00000003 (3): Alarm 1

H'00000004 (4): Alarm 2

H'00000005 (5): Alarm 3

H'00000006 (6): Program end output (See note 2.)

H'00000007 (7): Control output ON/OFF count alarm (See note 3.)

H'00000008 (8): Work bit 1

H'00000009 (9): Work bit 2

H'0000000A (10): Work bit 3

H'0000000B (11): Work bit 4

H'0000000C (12): Work bit 5

H'0000000D (13): Work bit 6

H'0000000E (14): Work bit 7

H'0000000F (15): Work bit 8

Advanced

function

setting

C3 (83) 004F Control Output 2 Assign-

ment

H'00000000 (0): Not assigned.

H'00000001 (1): Control output (heating)

H'00000002 (2): Control output (cooling)

H'00000003 (3): Alarm 1

H'00000004 (4): Alarm 2

H'00000005 (5): Alarm 3

H'00000006 (6): Program end output (See note 2.)

H'00000007 (7): Control output ON/OFF count alarm (See note 3.)

H'00000008 (8): Work bit 1

H'00000009 (9): Work bit 2

H'0000000A (10): Work bit 3

H'0000000B (11): Work bit 4

H'0000000C (12): Work bit 5

H'0000000D (13): Work bit 6

H'0000000E (14): Work bit 7

H'0000000F (15): Work bit 8
