E5CC-800/E5CC-B-800/E5CC-U-800
17
● E5CC-U-800 Wiring Socket
Front-connecting Socket
P2CF-11
Back-connecting Socket
P3GA-11
● Watertight Cover
Y92A-48N
● Mounting Adapter
Y92F-49
● Protective Cover ● Protective Cover
Y92A-48H
67.6
69
12
21.9 14
(2)
79.2
87.7
28.9
The Mounting Adapter is provided with
the Temperature Controller.
Order this Adapter separately if it
becomes lost or damaged.
This Protective Cover is soft type.
It is able to operate the controller
with using this cover.
Note: This Protective Cover cannot be used
if the Waterproof Packing is installed.
Y92A-48D
This Protective Cover is hard type.
Please use it for the mis-operation
prevention etc.
40
±0.2
4.5
567
8
4
3
21
9
10 11
70 max.
4
Eleven, M3.5 × 7.5
sems screws
7.8
Two,
4.5-dia.
holes
50 max.
3
31.2 max.
35.4
Mounting Holes
Terminal Layout/Internal Connections
(Top View)
Two, 4.5 dia. mounting holes
Note: 1. A model with finger protection (P2CF-11-E) is also available.
2. You cannot use the P2CF-11 or P2CF-11-E together with the Y92F-45.
Note: Can also be mounted
to a DIN track
5 6 7 8
4
3
2
9
10
11
1
25.6
27dia.
45
45
4.5 16.3 6.2
47
3
8.7
6
Terminal Layout/Internal Connections
(Bottom View)
Eleven, M3.5
sems screws
Note: 1. Using any other sockets will adversely affect accuracy. Use only the specified sockets.
2. A Protective Cover for finger protection (Y92A-48G) is also available.
3. You cannot use the P3GA-11 together with the Y92F-45.
