Omron E5CC-QX2ASM-802 User Manual

E5CC-800/E5CC-B-800/E5CC-U-800
14
Dimensions (Unit: mm)
Controllers
45
+0.6
0
45
+0.6
0
45
+0.6
0
60 min.
(48 × number of units - 2.5)
+1.0
0
Panel Cutout
Mounted Separately Group Mounted
48 × 48
4
1
73.1
60
Adapter
(Accessory)
Terminal Cover
(E53-COV17)
(Sold separately)
5848.8
Waterproof Packing
(Accessory)
44.8 × 44.8
44.8 × 44.8
E5CC-800
• Recommended panel thickness is 1 to 5 mm.
• Group mounting is not possible in the vertical direction. (Maintain
the specified mounting space between Controllers.)
• To mount the Controller so that it is waterproof, insert the
waterproof packing onto the Controller.
• When two or more Controllers are mounted, make sure that the
surrounding temperature does not exceed the allowable operating
temperature specified in the specifications.
(71.4)
67.4
4
(1)
58
Adapter
(Accessory)
48 × 48
44.8 × 44.8
44.8 × 44.8
Waterproof Packing
(Accessory)
E5CC-B-800
58
76.8
58.6
4
14.2
48 × 48
Adapter
(Accessory)
44.8 × 44.8
45
+0.6
0
45
+0.6
0
45
+0.6
0
60 min.
(48 × number of units - 2.5)
+1.0
0
Panel Cutout
Mounted Separately Group Mounted
E5CC-U-800
• Recommended panel thickness is 1 to 5 mm.
• Group mounting is not possible in the vertical direction. (Maintain
the specified mounting space between Controllers.)
• When two or more Controllers are mounted, make sure that the
surrounding temperature does not exceed the allowable operating
temperature specified in the specifications.

Omron E5CC-QX2ASM-802 Specifications

General

Brand	Omron
Model	E5CC-QX2ASM-802
Category	Temperature Controller
Language	English
