E5DC-800
40
Model Number Legend and Standard Models
Model Number Legend
●Models with Screw Terminals
E5DC-800 22.5 × 96 mm
*1 The control output can be used as a simple transfer output for the Digital Temperature Controllers manufactured in July 2014 or later.
*2 Option 000 can be selected only if two auxiliary outputs are selected.
Options 002 and 017 can be selected only if the control output is a relay output or voltage output and two auxiliary outputs are selected.
Option 015 cannot be selected if the control output is a relay output or voltage output and two auxiliary outputs are selected.
Options 016 can be selected only if the control output is a linear current output and two auxiliary outputs are selected.
Control output Auxiliary output Communications Heater burnot Event inputs Power supply voltage Model *2
Relay output
--- RS-485
---
---
100 to 240 VAC
E5DC-RX0ASM-815
E5DC-RX0AUM-815
Voltage output
E5DC-QX0ASM-815
E5DC-QX0AUM-815
Linear current output *1
E5DC-CX0ASM-815
E5DC-CX0AUM-815
Relay output
24 VAC/VDC
E5DC-RX0DSM-815
E5DC-RX0DUM-815
Voltage output
E5DC-QX0DSM-815
E5DC-QX0DUM-815
Linear current output *1
E5DC-CX0DSM-815
E5DC-CX0DUM-815
Relay output
Two
---
100 to 240 VAC
E5DC-RX2ASM-800
E5DC-RX2AUM-800
Voltage output
E5DC-QX2ASM-800
E5DC-QX2AUM-800
Linear current output *1
E5DC-CX2ASM-800
E5DC-CX2AUM-800
Relay output
24 VAC/VDC
E5DC-RX2DSM-800
E5DC-RX2DUM-800
Voltage output
E5DC-QX2DSM-800
E5DC-QX2DUM-800
Linear current output *1
E5DC-CX2DSM-800
E5DC-CX2DUM-800
Relay output
RS-485
Detection for Single-phase
heater
100 to 240 VAC
E5DC-RX2ASM-802
E5DC-RX2AUM-802
Voltage output
E5DC-QX2ASM-802
E5DC-QX2AUM-802
Linear current output *1 ---
E5DC-CX2ASM-815
E5DC-CX2AUM-815
Relay output
Detection for Single-phase
heater
24 VAC/VDC
E5DC-RX2DSM-802
E5DC-RX2DUM-802
Voltage output
E5DC-QX2DSM-802
E5DC-QX2DUM-802
Linear current output *1 ---
E5DC-CX2DSM-815
E5DC-CX2DUM-815
Relay output
---
Detection for Single-phase
heater
One
100 to 240 VAC
E5DC-RX2ASM-817
E5DC-RX2AUM-817
Voltage output
E5DC-QX2ASM-817
E5DC-QX2AUM-817
Linear current output *1 ---
E5DC-CX2ASM-816
E5DC-CX2AUM-816
Relay output
Detection for Single-phase
heater
24 VAC/VDC
E5DC-RX2DSM-817
E5DC-RX2DUM-817
Voltage output
E5DC-QX2DSM-817
E5DC-QX2DUM-817
Linear current output *1 ---
E5DC-CX2DSM-816
E5DC-CX2DUM-816
