Omron E5CK - Expansion Mode

I-80 Digital Controller E5CK
Expansion Mode
1300
-200
s l - l
pid
off
15.0
0.65
1.0
0
1
0.2
0.2
c n t l
s
t
l
b a b
a
l f a
a
t - g
r
s e t
s
l - h
r
e t
a
t - h
s
t - b
SP Setting Upper Limit
SP Setting Lower Limit
PID/ON/OFF
ST
Available if the Controller in standard control or advanced PID control has a temperature input.
ST Stable Range
α
Available if the Controller is in advanced PID control with the ST set to OFF.
AT Calculated Gain
Available if the Controller is in advanced PID control with the ST set to OFF.
Standby Sequence Reset Method
Automatic Return of Display Mode
AT Hysteresis
Available if the Controller is in advanced PID control with the ST set to OFF.
LBA Detection Width
Available only when the LBA (loop break alarm) function of the Controller is selected.
Available if the Controller in standard control or advanced PID control with the ST set to ON has a tem-
perature input.
