Omron E5CN-HR2M-500

E5CN-H
10
Isolation/Insulation Block Diagrams
Nomenclature
Dimensions (Unit: mm)
Accessories (Order Separately)
USB-Serial Conversion Cable
Temperatureinput/Analoginput/CTinput/Voltagepulseoutput
Communications/Eventinputs
Linearcurrentoutput/Linearvoltageoutput
Transferoutput
Relayoutput
Auxiliaryoutput1,2
Power
supply
:Reinforcedinsulation
:Functionalinsulation
E5CN-H
E5CN-H
SUB1
OUT1
OUT2
STOP
CMW
MANU
SUB2
SUB3
HA
Level Key
Temperature unit
No. 1 display
No. 2 display
Up Key
Mode Key Down Key
Operation indicators
45
+0.6
0
45
+0.6
0
45
+0.6
0
60 min.
(48 × number of units − 2.5)
+1.0
0
Group mounting does not
allow waterproofing.
Panel Cutout
Mounted Separately Group Mounted
48 × 48
44.8 × 44.8 48.8
6
1.5
91
78
58
Terminal Cover
(E53-COV17)
(Accessory)
Mounting Adapter
(Accessory)
Waterproof
Packing
(Accessory)
E5CN-H
• Recommended panel thickness is 1 to
5mm.
• Group mounting is not possible in the
vertical direction. (Maintain the specified
mounting space between Controllers.)
• To mount the Controller so that it is
waterproof, insert the waterproof packing
onto the Controller.
• When two or more Controllers are mounted,
make sure that the surrounding
temperature does not exceed the allowable
operating temperature specified in the
specifications.
Note: The terminal block cannot be removed.
(2,100)
250
1,765
USB connector (type A plug) Serial connecto
r
LED indicator (RD)
LED indicator
(SD)
E58-CIFQ1
