Omron E5CN-R2MT-500 User Manual

4 Digital Temperature Controllers E5CN/E5CN-U
Model Number Structure
■ Model Number Legend (Plug-in-type Controllers)
1. Output type
R: Relay
Q: Voltage
2. Number of alarms
Blank: No alarm
1: One alarm
2: Two alarms
3. Input type
T: Thermocouple/platinum resistance thermometer (multi-input)
4. Plug-in type
U: Plug-in type
Ordering Information (Plug-in-type Controllers)
■ Controllers with Temperature Inputs (Multi-input)
Note: Option Units (E53-CN@@N) cannot be used for Plug-in models.
■ Accessories (Order Separately)
USB-Serial Conversion Cable
Terminal Cover
Note: The Terminal Cover comes with the E5CN-@@@-500 models.
Current Transformers (CTs)
Adapter
Note: Use this Adapter when the panel has been previously prepared
for the E5B@.
Sockets
(for Models with Plug-in Connectors)
1 2 3 4
E5CN-@@@U
Size Power supply voltage Number of alarm points Control outputs Model
1/16 DIN 100 to 240 VAC 0 Relay E5CN-RTU
Voltage (for driving SSR) E5CN-QTU
1 Relay E5CN-R1TU
Voltage (for driving SSR) E5CN-Q1TU
2 Relay E5CN-R2TU
Voltage (for driving SSR) E5CN-Q2TU
24 VAC/DC 0 Relay E5CN-RTU
Voltage (for driving SSR) E5CN-QTU
1 Relay E5CN-R1TU
Voltage (for driving SSR) E5CN-Q1TU
2 Relay E5CN-R2TU
Voltage (for driving SSR) E5CN-Q2TU
Model
E58-CIFQ1
Connectable models Terminal type
Model E53-COV10
Model E54-CT1 E54-CT3
Hole diameter 5.8 dia. 12.0 dia.
Connectable models Terminal type
Model Y92F-45
Model P2CF-11 P2CF-11-E P3GA-11 Y92A-48G
Type Front-
connecting
Socket
Front-
connecting
Socket with
Finger
Protection
Back-
connecting
socket
Terminal
Cover for
Finger
Protection
