Omron E5EN-H Communications Manual

Com Data for CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-4
Note 1: The parameter for the currently selected bank will be accessed.
Note 2: The parameter for the currently selected PID set will be accessed. For setup area 1, however, the currently selected PID
set is fixed at PID1.
Variable
type
Address Parameter name Setting (monitor) value Level
C1 (81) 0022 MV at Stop Standard: H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
Heating/cooling: H'FFFFFBE6 to H'0000041A (
−105.0 to 105.0)
Position proportional (Floating or direct setting of position proportional
MV OFF): H'FFFFFFFF to H'00000001 (
−1 to 1)
Position proportional (Closed and direct setting of position proportional
MV ON): H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
Adjustment
C1 (81) 0023 MV at PV Error Standard: H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
Heating/cooling: H'FFFFFBE6 to H'0000041A (
−105.0 to 105.0)
Position proportional (Floating or direct setting of position proportional
MV OFF): H'FFFFFFFF to H'00000001 (
−1 to 1)
Position proportional (Closed and direct setting of position proportional
MV ON): H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
C1 (81) 0024 Manual MV Standard: H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
Heating/cooling: H'FFFFFBE6 to H'0000041A (
−105.0 to 105.0)
Position proportional (Floating or direct setting of position proportional
MV OFF): H'FFFFFFFF to H'00000001 (
−1 to 1)
Position proportional (Closed and direct setting of position proportional
MV ON): H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
Manual
Control
C1 (81) 0025 SP Ramp Set Value (See note 1.) H'00000000(0): OFF
H'00000001 to H'00007E90 (1 to 32400)
Adjustment
C1 (81) 0026 MV Upper Limit (See note 2.) Standard: MV lower limit + 0.1 to H'0000041A
(MV lower limit + 0.1 to 105.0)
Heating/cooling: H'00000000 to H'0000041A (0.0 to 105.0)
Position proportional (closed): MV lower limit +0.1 to H'0000041A
(MV lower limit +0.1 to 105.0)
C1 (81) 0027 MV Lower Limit (See note 2.) Standard: H'FFFFFFCE to MV upper limit
−0.1
(
−5.0 to MV upper limit −0.1)
Heating/cooling: H'FFFFFBE6 to H'00000000 (
−105.0 to 0.0)
Position proportional (closed): H'FFFFFFCE to MV upper limit
−0.1
(
−5.0 to MV upper limit −0.1)
C1 (81) 0028 Move to Protect Level H'FFFFF831 to H'0000270F (
−1999 to 9999) Protect
C1 (81) 0029 Password to Move to Protect Level H'FFFFF831 to H'0000270F (
−1999 to 9999)
(Can only be set. The monitor value is always H’00000000.)
C1 (81) 002A Parameter Mask Enable H'00000000 (0): OFF
H'00000001 (1): ON
C1 (81) 002B PF Key Protect H'00000000 (0): OFF
H'00000001 (1): ON
C1 (81) 002C MV Change Rate Limit H'00000000 to H'000003E8 (0.0 to 100.0) Adjustment
C1 (81) 002D Position Proportional Dead Band H'00000001 to H'00000064 (0.1 to 10.0)
C1 (81) 002E Open/Close Hysteresis H'00000001 to H'000000C8 (0.1 to 20.0)
C1 (81) 002F Heater Overcurrent Detection 1 H'00000000 to H'000001F4 (0.0 to 50.0)
C1 (81) 0030 Heater Overcurrent Detection 2 H'00000000 to H'000001F4 (0.0 to 50.0)
C1 (81) 0031 Extraction of Square Root Low-cut
Point
H'00000000 to H'000003E8 (0.0 to 100.0)

Omron E5EN-H Specifications

General

Output Type	Relay, Voltage, Current
Sampling Period	100 ms
Number of Control Outputs	1 or 2
Type	Digital Controller
Input Type	Thermocouple, RTD
Power Supply	100 to 240 VAC
Control Method	PID control
Communication	RS-485
Dimensions	96 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
