Omron G2RV - Complete Unit

8 Slim Relay G2RV
■ Separating Plates
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Complete Unit
G2RV-SL700
Model number Description
P2RV-S Provides isolation between adjacent relays to
achieve 400 V isolation.
12
11
14
A1
A2
24 V DC
Terminal Arrangement/
Internal Connections
(Top View)
12
11
14
A1
A2
12 V DC
Terminal Arrangement/
Internal Connections
(Top View)
12
11
14
A1
A2
Other Coil Voltage
Terminal Arrangement/
Internal Connections
(Top View)
Five,
M2.5 × 6
6.2 max.
99.2
7.188.9
26.1
47.2
70.9
83
106.7 max.
92.7 max.
35
Input circuit
