Omron G3PE - Page 17

Three-phase G3PE
17
Accessories (Order Separately)
Heat Sink
Y92B-P50 (Mounts to DIN Track.)
For G3PE-215B-2H and
G3PE-515B-2H
Heat Sink
Y92B-P100
For G3PE-215B-3H,
G3PE-225B-2H,
G3PE-515B-3H, and
G3PE-525B-2H
Heat Sink
Y92B-P150
For G3PE-225B-3H,
G3PE-235B-2H,
G3PE-525B-3H, and
G3PE-535B-2H
Heat Sink
Y92B-P200
For G3PE-235B-3H,
G3PE-245B-2H,
G3PE-535B-3H, and
G3PE-545B-2H
Heat Sink
Y92B-P250
For G3PE-245B-3H and
G3PE-545B-3H
68 90
68
50
80 max.
80.5
max.
55 max.
100
max.
4.6 dia.
4.6 × 5.6
elliptical
hole
50
±0.3
90
±0.3
Two, 4.5 dia. or M4
Mounting Holes
68
110.5 max.
60
68
Four, M4
100
80.5
max.
70 max.
Four,
R2.5
60
±0.3
100
±0.3
Four, 4.5 dia. or M4
Mounting Holes
5
90
±0.3
100
±0.3
Four, 4.5 dia. or M4
Mounting Holes
68
90
68
100
110.5 max.
110.5
max.
70 max.
Four, M4
5
Four,
R2.5
Mounting Holes
68
120
70 max.
68
120
130.5 max.
Four, M4
90
±0.3
120
±0.3
90
130.5
max.
5
Four, 4.5 dia. or M4
Four,
R2.5
5
68
68
47.6
Four, M4M4-D10
M4-D10
120
120
130.5 max.
190.5
max.
70 max.
150
150
±0.3
120
±0.3
Four, 4.5 dia. or M4
Mounting Holes
Four,
R2.5
