Omron G3PE - Heat Sinks

Three-phase G3PE
9
Characteristics
Models with Built-in Heat Sinks
* The leakage current of phase S will be approximately √3 times larger if the 2-element model is used.
Models with Externally Attached Heat Sinks
* The leakage current of phase S will be approximately √3 times larger if the 2-element model is used.
Heat Sinks
Model G3PE-
215B-
3(N)
G3PE-
215B-
2(N)
G3PE-
225B-
3(N)
G3PE-
225B-
2(N)
G3PE-
235B-
3(N)
G3PE-
235B-
2(N)
G3PE-
245B-
3(N)
G3PE-
245B-
2(N)
G3PE-
515B-
3(N)
G3PE-
515B-
2(N)
G3PE-
525B-
3(N)
G3PE-
525B-
2(N)
G3PE-
535B-
3(N)
G3PE-
535B-
2(N)
G3PE-
545B-
3(N)
G3PE-
545B-
2(N)
Item
Operate
time
1/2 of load power source cycle + 1 ms max.
Release
time
1/2 of load power source cycle + 1 ms max.
Output ON
voltage drop
1.6 V (RMS) max. 1.8 V (RMS) max.
Leakage
current *
10 mA max. (at 200 VAC) 20 mA max. (at 480 VAC)
Insulation
resistance
100 MΩ min. (at 500 VDC)
Dielectric
strength
2,500 VAC, 50/60 Hz for 1 min
Vibration
resistance
• DIN Track mounting: 10 to 55 to 10 Hz, 0.175-mm single amplitude (0.35-mm double amplitude)
• Screw mounting: 10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude)
Shock resis-
tance
294 m/s
2
(reverse mounting: 98 m/s2)
Ambient
storage tem-
perature
−30 to 100°C (with no icing or condensation)
Ambient op-
erating tem-
perature
−30 to 80°C (with no icing or condensation)
Ambient op-
erating hu-
midity
45% to 85%
Weight Approx. 1.25 kg
Ap-
prox.
1.45 kg
Ap-
prox.
1.25 kg
Ap-
prox.
1.65 kg
Ap-
prox.
1.45 kg
Ap-
prox.
2.0 kg
Ap-
prox.
1.65 kg
Approx. 1.25 kg
Ap-
prox.
1.45 kg
Ap-
prox.
1.25 kg
Ap-
prox.
1.65 kg
Ap-
prox.
1.45 kg
Ap-
prox.
2.0 kg
Ap-
prox.
1.65 kg
Model G3PE-
215B-
3H
G3PE-
215B-
2H
G3PE-
225B-
3H
G3PE-
225B-
2H
G3PE-
235B-
3H
G3PE-
235B-
2H
G3PE-
245B-
3H
G3PE-
245B-
2H
G3PE-
515B-
3H
G3PE-
515B-
2H
G3PE-
525B-
3H
G3PE-
525B-
2H
G3PE-
535B-
3H
G3PE-
535B-
2H
G3PE-
545B-
3H
G3PE-
545B-
2H
Item
Operate
time
1/2 of load power source cycle + 1 ms max.
Release
time
1/2 of load power source cycle + 1 ms max.
Output ON
voltage drop
1.6 V (RMS) max. 1.8 V (RMS) max.
Leakage
current *
10 mA max. (at 200 VAC) 20 mA max. (at 480 VAC)
Insulation
resistance
100 MΩ min. (at 500 VDC)
Dielectric
strength
2,500 VAC, 50/60 Hz for 1 min
Vibration
resistance
10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude)
Shock resis-
tance
Destruction: 294 m/s
2
Ambient
storage tem-
perature
−30 to 100°C (with no icing or condensation)
Ambient op-
erating tem-
perature
−30 to 80°C (with no icing or condensation)
Ambient op-
erating hu-
midity
45% to 85%
Weight Approx. 300 g
Model Weight
Y92B-P50 Approx. 450 g
Y92B-P100 Approx. 450 g
Y92B-P150 Approx. 600 g
Y92B-P200 Approx. 850 g
Y92B-P250 Approx. 1,200 g
