Omron H2C User Manual

6 Motor Timer H2C
Dimensions
Note: All units are in millimeters unless otherwise indicated.
44.8 x 44.8
45
+0.6
−0
45
+0.6
−0
H2C/H2C-S/H2C-R/H2C-SR/H2C-8/H2C-8R
H2C-F/H2C-FR
For Flush Mounting
Mounting Holes
For a load current of 3 A max., dimension L becomes
3 mm min. with an interval of 0 mm between timers.
For a load current of 6 A max., dimension L becomes
8 mm min. with an interval of 5 mm between timers.
When using in locations with high ambient
temperatures, ensure that there is an interval of at
least 5 mm between timers.
For a load current of 1 A max., dimension L becomes
10 mm min. with an interval of 0 mm between timers.
For a load current of 3 A max., dimension L becomes
15 mm min. with an interval of 5 mm between timers.
For a load current of 6 A max., dimension L becomes
20 mm min. with an interval of 10 mm between timers.
Two, M4 or 4.5 dia. holes
37 dia.
100.8 *
103.1 *
80
16.3
16.3
85.7
81.5
92.2
H2C-8
H2C-8R
*These dimensions vary with the kind of DIN track (reference value).
Y92F-30
P3GA-11
Y92F-30
P3G-08
H2C
H2C-S
H2C-R
H2C-SR
P2CF-11
P2CF-11-E
P2CF-08
P2CF-08-E
H2C
H2C-S
H2C-R
H2C-SR
+
Adapter
(When
Y92A-48G
mounted)
H2C-8
H2C-8R
+
Adapter
(When
Y92A-48G
mounted)
Dimensions with Front Connecting Socket
P2CF-08-@/P2CF-11-@
Dimensions with Back Connecting Socket
P3G-08/P3GA-11
