Omron H2C - H2 C Mounting Accessories; Mounting Tracks and Plates; Spacers and Protective Covers; Hold-down Clips

Motor Timer H2C 9
Mounting Track
Timer Hold-down Clips
4.5
15 25 25 25 25
10 10
7.3±0.15
35±0.3
27±0.15
1
4.5
15 25 25 25 25 15
10 10
35±0.3
27
24
16
29.2
11.5
1,000
PFP-100N2PFP-100N, PFP-50N
1,000 (500)
(see note)
Note: The value shown in parentheses are for the
PFP-50N.
15 (5)
(see note)
50
11.5
10
6.2
1.8
1
35.5 35.3
1.8
1.3
4.8
5
16
12
44.3
34.8
16.5
10
End Plate
PFP-M
M4 x 8
pan head
screw
Spacer
PFP-S
Y92A-Y1 Y92A-48B
Time Setting Ring Protective Cover
The time setting ring locks the time setting knob to
store the set time to facilitate its resetting. A maximum
of two time setting rings are connectable per timer.
The protective cover shields the front panel, particular-
ly the time setting section, from dust, dirt, and water,
as well as prevents the set value from being altered
due to accidental contact with the time setting knob.
Y92H-2
(for PF085A/PF113A
Connecting Socket)
Y92H-1
(for PL08/PL11
Connecting Socket)
