H5CR
H5CR
185
Dimensions
Note: All units are in millimeters unless otherwise indicated.
H5CR-L
Panel Mounting/Surface Mounting
M3.5 terminal screw
(effective length: 6 mm)
H5CR-B
Panel Mounting
H5CR-S
Panel Mounting
M3.5 terminal screw
(effective length: 6 mm)
48
48
84.0
63.7
60.7
14.3
44.8
48
48
100
6
44.8
48
48
6
64
44.8
