Omron H3BA User Manual

H5CR
H5CR
186
H5CR-L
Panel Mounting Adapter
H5CR-B
H5CR-S
Panel Cutouts
Panel cutouts are
as shown below.
(according to DIN43700).
Surface Mounting
Y92F-30
Panel mounting adapter
Panel
Y92F-30
Panel mounting adapter
Panel
Note 1. The mounting panel thickness
should be 1 to 4 mm.
2. It is possible to mount timers
side by side, but only horizontally.
48
58
6
85.9
92.8
H5CR-L
P2CF-08
58
48
6
100
58
48
664
60 min.
60 min.
A
45
+0.6
-- 0
45
+0.6
-- 0
+0.6
-- 0
A = {n x 45 + (n-1) x 3.5}
Panel
Y92F-30
Panel mounting
adapter
P3G-08
Rear surface
connection socket
44.8
44.8

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
