Omron H3BA User Manual

H2A
H2A
221
Operation
Timing Chart
H2A H2A-H
Rt: Resetting time Rt: Resetting time
Dimensions
Note: All units are in millimeters unless otherwise indicated.
H2A/H2A-H
Note: F-shaped hook (PHC-1)
for PF085A and L-shaped
hook (PHc-4) for PL08 are
supplied with the timer.
H2A(-H) with Adapter
Panel Cutouts
Note: Back connecting socket US08 and Y-shaped hook
PHC-3aresuppliedwiththetimers.
Panel
Y92F-40 adapter for
flush mounting
(See note)

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
