Omron H3BA User Manual

H3CT
H3CT
324
Accessories (Order Separately)
Track Mounting Socket
P2CF-08
Terminal Arrangement/
Internal Connections
(Top View)
Surface Mounting Holes
40
+
0.2
Two, 4.5 dia. or two, M4
Eight
M3.5 x 7.5 sems
Two 4.5 dia.
holes
70 max.
50 max.
20.3 max.
7.8
34.5
35.4
4
Back Connecting Socket
P3G-08
Terminal Arrangement/
Internal Connections
(Bottom View)
45
27 dia.
45
4.9
17
Two, 2 dia.
holes
Mounting HolesTerminal Arrangement
(Bottom View)
PL08
Two, 3.5 dia. or 3M
socket mounting holes
Installation
Terminal Arrangement
(--)
(~)
(+)
(~)
Power supply
H3CT-8A H3CT-8H
(--)
(~)
(+)
(~)
Power supply

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
