H3DR-A/P/M
H3DR-A/P/M
66
Model Legend of H3DR Series
H3DR
-P -M
Full-multifunction Multifunction Single-function
-A
-A -AP
-AS
-AS -ASP
-A
-P -PP
DPDT Output Transistor
Output
NPN Input PNP Input
NPN Input PNP Input NPN Input PNP Input
Ordering Information
NPN (No-voltage) Input Models
Supply voltage Outputs Time range Operating mode Model
100 to 240 VAC (50/60 Hz) Contact (DPDT) 0.10 s to 120 h ON-delay, Flicker OFF start H3DR-A
12 VDC
(7 multi-range) Flicker ON start, Signal ON/OFF-delay
24 VDC/VAC (50/60 Hz) Signal OFF delay, Interval
12 VDC Transistor (6 multi-mode) H3DR-AS
24 VDC/VAC (50/60 Hz) (Photocoupler)
100 to 120 VAC (50/60 Hz) Contact (SPDT) H3DR-P
200 to 240 VAC (50/60 Hz)
24 VDC/VAC (50/60 Hz)
PNP (Voltage) Input Models
Supply voltage Outputs Time range Operating mode Model
100 to 240 VAC (50/60 Hz) Contact (DPDT) 0.10 s to 120 h ON-delay, Flicker OFF start H3DR-AP
12 VDC
(7 multi-range) Flicker ON start, Signal ON/OFF-delay
24 VDC/VAC (50/60 Hz) Signal OFF delay, Interval
12 VDC Transistor (6 multi-mode) H3DR-ASP
24 VDC/VAC (50/60 Hz) (Photocoupler)
100 to 120 VAC (50/60 Hz) Contact (SPDT) H3DR-PP
200 to 240 VAC (50/60 Hz)
24 VDC/VAC (50/60 Hz)
No-input Models
Supply voltage Outputs Time range Operating mode Model
110 to 120 VAC (50/60 Hz) Contact (SPDT) 1 s, 5 s, 10 s, 30 s, ON-delay H3DR-M
220 to 240 VAC (50/60 Hz)
60 s, 10 min
24 VDC/VAC (50/60 Hz) (single-time range)
Note: 1. Specify both the model number and supply voltage when ordering.
Example: H3DR-A/-P 24 VDC/VAC (50/60 Hz)
2. Specify both the model number, supply voltage, and time range when ordering.
Example: H3DR-M 220 to 240 VAC (50/60 Hz) 30 s
3. Order H3DR-M Timers in lots of 10 pcs (sold as a single package).
Supply voltage Time range
Supply voltage

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
