H3DR-A/P/M
H3DR-A/P/M
67
Accessories (Order Separately)
Mounting Track 50 cm (
l
)x7.3mm(t) PFP-50N
1m(
l
)x7.3mm(t) PFP-100N
1m(
l
)x16mm(t) PFP-100N2
End Plate PFP-M
Spacer PFP-S
Specifications
General
Item H3DR-A/-AS H3DR-AP/-ASP H3DR-P H3DR-PP H3DR-M
Operating mode A: ON-delay
B: Flicker OFF start
B2: Flicker ON start
C: Signal ON/OFF-delay
D: Signal OFF-delay
E: Interval
ON-delay
Terminal block 11/12 terminal 6/12 terminal 5/12 terminal
Input type No-voltage input
(NPN Model)
Voltage input
(PNP Model)
No-voltage input
(NPN Model)
Voltage input
(PNP Model)
---
Output type H3DR-A: Relay output (DPDT);
H3DR-AS: Transistor output
(NPN/PNP) (see note)
Relay output (SPDT)
Mounting method DIN track mounting
EMC Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
Immunity ESD: IEC801-2: 4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference: ENV50140: 10 V/m (80 MHz to 1 GHz) (level 3)
Immunity Conducted Disturbance: ENV50141: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: IEC801-4: 2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Approved standards UL508, CSA C22.2 No.14
Conforms to VDE 0435/2021 C/250, C/30 (-AS model), VDE 0110, VDE0106/P100,
IEC947 AC-15 (-P
j
and -M models), AC-13 (-A
j
model), DC-13 (-AS
j
model)
Conforms to EN50081-2, prEN50082-2
Note: The internal circuits are optically isolated from the output. This enables application of either NPN or PNP transistors.
Time Ranges
H3DR-A
j
/-AS
j
/-P
j
Time unit s (sec) min h(hrs) x10 h (10 h)
Setting 0 Instantaneous output (see note)
Time scale: x 0.1 0.1to1.2 1to12
Time scale: x 1 1to12 10 to 120
Note: To obtain instantaneous output, set the value below zero.
H3DR-M Single-time Range
Rated time Time range
1s 0.1to1s
5s 0.2to5s
10 s 0.5to10s
30 s 1to30s
60 s 2to60s
10 min 0.5to10min
