Omron H3BA User Manual

H3DR-A/P/M
H3DR-A/P/M
69
No-input Models
Item H3DR-M
Rated supply
voltage
110 to 120 VAC (50/60 Hz),
220 to 240 VAC (50/60 Hz),
24 VDC/VAC (50/60 Hz)
Operating
voltage range
85% to 110% of rated supply voltage
Power reset Minimum power-opening time: 0.1 s
Power
consumption
110 to 120 VAC: approx. 6 VA
220 to 240 VAC: approx. 10 VA
24 VDC/VAC: approx. 2 VA (AC)
approx. 1 W (DC)
Control
outputs
Contacts: 5 A at 250 VAC, resistance load (cos
%
=1)
Ambient
temperature
Operating:--10
"
Cto55
"
C (with no icing)
Storage: --25
"
Cto65
"
C (with no icing)
Ambient
humidity
Operating: 35% to 85%
Humidity
class
DIN 40 040: G
Characteristics
NPN (No-voltage) Input Models
Item H3DR-A/-AS/-P
Accuracy of operating
time
!
1% FS max. (
!
1%
!
10 ms in a range of 1.2 s)
Setting error
!
10% FS
!
0.05 s max.
Reset time Min. power-opening time: 0.1 s; Min. pulse width: 0.05 s
Reset voltage 10% max. of rated supply voltage
(10 V max. for 100 to 240 VAC, 100 to 120 VAC;
20 V max. for 200 to 240 VAC)
Influence of voltage
!
0.5% FS max. (
!
0.5% FS
!
10 ms max. in a range of 1.2 s)
Influence of temperature
!
2% FS max. (
!
2% FS
!
10 ms max. in a range of 1.2 s)
Insulation resistance 100 M
$
min. (at 500 VDC)
Dielectric strength 2,000 VAC (1,000 VAC for -AS model), 50/60 Hz for 1 min (between current-carrying terminal and
non-current-carrying metal parts)
2,000 VAC (1,000 VAC for -AS model), 50/60 Hz for 1 min (between control output terminals and
operating circuit)
1,000 VAC, 50/60 Hz for 1 min (between contacts not located next to each other) (except -AS model)
Impulse withstand voltage 3 kV (between power terminals) for 100 to 120 VAC, 110 to 120 VAC, 200 to 240 VAC, 220 to 240 VAC,
100 to 240 VAC, 1 kV for 12 VDC, 24 VDC/VAC
4.5 kV (between current-carrying terminal and exposed non-current-carrying metal parts) for 100 to
120 VAC, 110 to 120 VAC, 200 to 240 VAC, 220 to 240 VAC, 100 to 240 VAC, 1.5 kV for 12 VDC,
24 VDC/VAC
Noise immunity
!
1.5 kV (between power terminals) (
!
400 V for 12 VDC) and
!
600 V (between input terminals),
square-wave noise by noise simulator (pulse width: 100 ns/1
&
s, 1-ns rise)
Static immunity Malfunction:4 kV
Destruction:8 kV
Vibration resistance Destruction:10 to 55 Hz with 0.75-mm double amplitude each in three directions
Malfunction:10 to 55 Hz with 0.5-mm double amplitude each in three directions
Shock resistance Destruction:980 m/s
2
(100G) each in three directions
Malfunction:98 m/s
2
(10G) each in three directions
Life expectancy Mechanical:20 million operations min. (under no load at 1,800 operations/h)
Electrical: 100,000 operations min. (5 A at 250 VAC, resistive load at 1,800 operations/h)
Enclosure rating IEC: IP40
Weight Approx. 120 g

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
