H3DR-A/P/M
H3DR-A/P/M
70
PNP (Voltage) Input Models
Item H3DR-AP/-ASP/-PP
Accuracy of operating
time
!
1% FS max. (
!
1%
!
10 ms in a range of 1.2 s)
Setting error
!
10% FS
!
0.05 s max.
Reset time Min. power-opening time: 0.1 s; Min. pulse width: 0.05 s
Reset voltage 10% max. of rated supply voltage
(10 V max. for 100 to 240 VAC, 100 to 120 VAC;
20 V max. for 200 to 240 VAC)
Influence of voltage
!
0.5% FS max. (
!
0.5% FS
!
10 ms max. in a range of 1.2 s)
Influence of temperature
!
2% FS max. (
!
2% FS
!
10 ms max. in a range of 1.2 s)
Insulation resistance 100 M
$
min. (at 500 VDC)
Dielectric strength 2,000 VAC (1,000 VAC for -ASP model), 50/60 Hz for 1 min (between current-carrying terminal and
non-current-carrying metal parts)
2,000 VAC (1,000 VAC for -ASP model), 50/60 Hz for 1 min (between control output terminals and
operating circuit, and contacts of different polarity)
1,000 VAC, 50/60 Hz for 1 min (between contacts not located next to each other)
Impulse withstand voltage 3 kV (between power terminals) for 100 to 120 VAC, 200 to 240 VAC, 100 to 240 VAC,
1 kV for 12 VDC, 24 VDC/VAC
4.5 kV (between current-carrying terminal and exposed non-current-carrying metal parts) for 100 to
120 VAC, 200 to 240 VAC, 100 to 240 VAC, 1.5 kV for 12 VDC, 24 VDC/VAC
Noise immunity
!
1.5 kV (between power terminals) (
!
400 V for 12 VDC) and
!
600 V (between input terminals),
square-wave noise by noise simulator (pulse width: 100 ns/1
&
s, 1-ns rise)
Static immunity Malfunction:4 kV
Destruction:8 kV
Vibration resistance Destruction:10 to 55 Hz with 0.75-mm double amplitude each in three directions
Malfunction:10 to 55 Hz with 0.5-mm double amplitude each in three directions
Shock resistance Destruction:980 m/s
2
(100G) each in three directions
Malfunction:98 m/s
2
(10G) each in three directions
Life expectancy Mechanical:20 million operations min.
Electrical: 100,000 operations min. (5 A at 250 VAC, resistive load at 1,800 operations/h)
Enclosure rating IEC: IP40
Weight H3DR-AP: approx. 130 g; H3DR-ASP: approx. 110 g; H3DR-PP: approx. 120 g

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
