Omron H3BA User Manual

H3DR-G
H3DR-G
95
Solid-state Star-delta Timer H3DR-G
DIN 22.5-mm Solid-state Star-delta
Timer
High immunity to invertor noise.
A wide star-time range (up to 120 seconds) and
star-delta transfer time range (up to 0.5 seconds).
RC
Ordering Information
Supply voltage Model
100 to 240 VAC H3DR-G
48 VAC
24 VAC/DC
Note: Specify both the model number and supply voltage when ordering.
Example: H3DR-G 24 VAC/DC
Supply voltage
Model Number Legend:
H3DR-
j
1
1. Classification
G: Star-delta timer
Specifications
General
Item H3DR-G
Terminal block 6 terminals used
Operating/Reset method Time-limit operation/Self-reset
Output type Time-limit: SPST-NO (star operation circuit)
SPST-NO (delta operation circuit)
Mounting method DIN track mounting
Approved standards UL508, CSA C22.2 No.14
Conforms to VDE0435/2021 C/250, VDE0110, VDE0106/P100
Conforms to EN50081-1, prEN50082-2
Attachment Name plate

Omron H3BA Specifications

General

Time Range	0.05 s to 300 h
Output Type	Relay
Contact Form	DPDT
Weight	Approx. 200 g
Operating Temperature	-10 to 55°C
Storage Temperature	-25 to 65°C
Dimensions	48mm x 48mm x 78mm
Type	Solid-state timer
