H3DR-F
H3DR-F
94
Timing Chart
Note: t
ON
:ONsettime
t
OFF:
OFF set time
Allow at least 0.1 s for recovery.
Power
ON
OFF
Output
0.1 s min.
ON
indicator
OFF
indicator
ON
OFF
ON
OFF
ON
OFF
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Installation
Terminal Arrangement
Power
supply
+
--
