Dimensions
Note: All units are in millimeters unless otherwise indicated.
Timers
H3Y-2 H3Y-4
(63.0)
6.4
6.3
(63.0)
6.4
6.3
28 max.
21.5
max.
21.5
max.
28 max.
Mounting Holes
H3Y-2-0 H3Y-4-0, H3Y-4-CB-0
Fourteen, 1.3-dia.
holes
Eight,
1.3-dia. holes
Mounting Holes
(60.7)
28 max.
(60.7)
28 max.
6.3
21.5
max.
6.3
21.5
max.
