H3T
H3T
146
Ratings
Rated supply voltage 12 or 24 VDC, permissible ripple: 5% max.
Switched by shorting and opening terminals.
Operating voltage range 12 V: 90% to 110% of rated voltage
24 V: 80% to 110% of rated voltage
Power consumption 12 V: Approx. 60 mW
24 V: Approx. 120 mW
Control output Solid-state output: 100 mA
Voltage drop: 1.2 V max. (see note 2)
Note: 1. Residual voltage on reset input when shorted: 1.0 V.
2. Contact output switching capacity: 100 mA, but rated coil current of relay loads must be 75 mA or less.
Characteristics
Accuracy of operating time
!
2% max. (Percentage of FS value, including initial value)
Setting error 0% to 100% FS (Percentage of FS value)
Reset time 1 ms max. (including resets during operation)
Influence of voltage
!
2% max. (Percentage of FS value)
Influence of temperature
!
5% max. at --10
"
Cto70
"
C (Percentage of FS value)
Insulation resistance 100 M
$
min. (at 250 VDC)
Dielectric strength 500 VAC, 50/60 Hz for 1 min (between all terminals, knob and case)
Vibration resistance Destruction: 10 to 55 Hz with 1.5-mm double amplitude
Malfunction: 10 to 55 Hz with 1.5-mm double amplitude
Shock resistance Destruction: 1,000 m/s
2
(approx. 100G)
Malfunction: 1,000 m/s
2
(approx. 100G)
Ambient temperature Operating: --10
"
Cto70
"
C (with no icing)
Storage: --25
"
Cto80
"
C (with no icing)
Ambient humidity Operating: 35% to 85%
Weight Approx. 10 g
Operation
Time Specifications and Terminals
Model Terminals
H3T-A 1s 10 s 1min 10 min
H3T-B 6s 60 s 6min 60 min
Note: 1. Short terminals 21 and 22 when using the internal adjustment (variable resistor) in the H3T.
2. An external resistor can be used by opening terminals 21 and 24. Connect the external resistor (2 M
$
for H3T-A and H3T-B) be-
tween terminals 21 and 24.
