H5BR

164

Operational Overview

Run mode

Present value,

set value

Batch count value,

set value

Timing range

Key protect level

Input signal time

Output time

Output mode

UP/DOWN mode

Setting mode

Press the

DISPLAY key

Press the

BATCH key

Press the

DISPLAY key

Press the

MODE key

Press the

MODE key

Press the

MODE key

Press the

MODE key

Press the

MODE key

Press the

MODE key

Press the

MODE key

Note: 1. Set values are changed using the increment keys

(1 to 4).

2. The large arrows indicate the parameter displayed first

when the mode is changed with the MODE or DISPLAY

key.
