Omron H3CR-A User Manual

H5CN
H5CN
206
Backup Battery
Y92S-20
Connection of Battery Leads
With socket
P2CF-11
With socket
P3G-11
Terminal No. 1 Terminal No. 4
Terminal No. 1 Terminal No. 4
Installation
Connections
Power Supply Connection
Model Without Backup Power for Memory Protection
Connectthe timersothatthe requiredsupply voltagecanbeapplied
across terminals
B
and
G
.
Model With Backup Power for Memory Protection
Connectthe timersothatthe requiredsupply voltagecanbeapplied
across terminals
B
and
J
.
Connection of Load Circuit (Control Output)
Model With Backup Power for Memory Protection
Contact Output Type (H5CN-
j
N)
Terminals
E
,
F
, and
H
are for contact output contacts. Load 1 con-
nected inseries withNOcontact(between terminals
F
and
H
)is nor-
mallyopen,andtheloadcircuitvoltagewillbe appliedafter thelapse
of the set time. The load circuit voltage is normally applied to load
B
conneted in series with NC contact (between terminals
E
and
H
),
which will be open after the lapse of the set time.
Load circuit
voltage
(250 VAC
max.)

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
