H5L
H5L
260
Dimensions
Note: All units are in millimeters unless otherwise indicated.
H5L-A
Mounting Dimensions
Flush Mounting
Use a U-shaped mounting bracket
to flush mount the unit.
Panel Cutout
Dimensions Mounting Bracket (Included)
