Omron H3CR-A User Manual

H3CT
H3CT
324
Accessories (Order Separately)
Track Mounting Socket
P2CF-08
Terminal Arrangement/
Internal Connections
(Top View)
Surface Mounting Holes
40
+
0.2
Two, 4.5 dia. or two, M4
Eight
M3.5 x 7.5 sems
Two 4.5 dia.
holes
70 max.
50 max.
20.3 max.
7.8
34.5
35.4
4
Back Connecting Socket
P3G-08
Terminal Arrangement/
Internal Connections
(Bottom View)
45
27 dia.
45
4.9
17
Two, 2 dia.
holes
Mounting HolesTerminal Arrangement
(Bottom View)
PL08
Two, 3.5 dia. or 3M
socket mounting holes
Installation
Terminal Arrangement
(--)
(~)
(+)
(~)
Power supply
H3CT-8A H3CT-8H
(--)
(~)
(+)
(~)
Power supply

Omron H3CR-A Specifications

General

Time Range	0.05 seconds to 300 hours
Output Type	Relay
Mounting Type	DIN Rail
Operating Temperature	-10°C to 55°C
Contact Form	SPDT
Number of Pins	8
Contact Rating	5A at 250VAC
Storage Temperature	-25°C to 65°C
Type	Solid State Timer
Dimensions	48 mm x 48 mm
Operating Mode	ON-delay, OFF-delay, Interval, One-shot
Operating Voltage	24V DC, 100-240V AC
