H3CR-H
H3CR-H
52
Accessories (Order Separately)
Name/specifications Models
Flush Mounting Adapter
Y92F-30
Y92F-70
Y92F-71
Mounting Track 50 cm (
l
)x7.3mm(t) PFP-50N
1m(
l
) x 7.3 mm (t) PFP-100N
1m(
l
)x16mm(t) PFP-100N2
End Plate PFP-M
Spacer PFP-S
Protective Cover Y92A-48B
Track Mounting/
8-pin P2CF-08
Front Connecting Socket
11-pin P2CF-11
Back Connecting Socket
8-pin P3G-08
11-pin P3GA-11
Hold-down Clip For PL08 and PL11 Sockets Y92H-1
For PF085A Socket Y92H-2
Specifications
General
Item H3CR-H8L H3CR-H8RL H3CR-HRL
Operating/Reset method Instantaneous
operation/Time-limit reset
Instantaneous operation/Time-limit reset/Forced reset
Pin type 8-pin 11-pin
Input type --- No-voltage
Output type Relay output (DPDT) Relay output (SPDT) Relay output (DPDT)
Mounting method DIN track mounting, surface mounting, and flush mounting
EMC Emission Enclosure: EN55011 Group 1 class A
Emission AC Mains: EN55011 Group 1 class A
Immunity ESD: IEC801-2: 4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference: ENV50140: 10 V/m (80 MHz to 1 GHz) (level 3)
Immunity Conducted Disturbance: ENV50141: 10 V (0.15 to 80 MHz) (level 3)
Immunity Burst: IEC801-4: 2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Approved standards UL508, CSA C22.2 No.14, LR/NK
Conforms to VDE0435/2021, VDE0110
Conforms to EN50081-2, prEN50082-2
Time Ranges
Time unit S-series M-series
s (sec) min
Setting 0.6 0.05 to 0.6
1.2 0.1to1.2
6 0.5to6
12 1to12
Min. power ON time 0.1 sec min. 2 sec min.
Note: If theaboveminimum power ONtimeisnotsecured, theH3CRmaynotoperate. Besuretosecure theaboveminimumpower ONtime.
