Omron H3CR-A8 User Manual

H3CR-A
H3CR-A
15
H3CR-A8E
Operating
mode
Timing chart
A:
ON-delay
Power
Output
t
Basic operation
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
B
2
:
Flicker ON
start
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
Power
Output
t
Basic operation
ttt
E:
Interval
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
Power
Output
t
Basic operation
J:
One-shot
output
Power
Output relay
(NC)
Power indicator
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
Output relay
(NO) (output
indicator)
Power
Output
t
Basic operation
1±0.6 s
(Fixed)
(Fixed) (Fixed)

Omron H3CR-A8 Specifications

General

Time Range	0.05 s to 300 h
Operating Temperature	-10 to 55°C
Terminal Type	Screw
Number of Pins	8
Contact Rating	5 A at 250 VAC
Storage Temperature	-25 to 65°C
Operating Voltage	100 to 240 VAC
Mounting Type	DIN Rail
Output Type	SPDT
Dimensions	48mm x 48mm
Operating Modes	Interval
