H3CR
H3CR
48
Track Mounting/Front Connecting Socket
P2CF-08
P2CF-08-E (Finger Safe Terminal Type)
Conforming to VDE0106/P100
T erminal Arrangement/
Internal Connections
(T op V iew)
Surface Mounting Holes
40±0.2
Two, 4.5 dia. or two, M4
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes
70 max.
50 max.
20.3 max.
7.8
3 4.5
35.4
4
50 max.
40±0.2
70 max.
Eight,
M3.5 x 7.5 sems
Two, 4.5 dia.
holes
7.8
4
35.4
21.5 max.
20.3
19
3
1.3
5 4.5
Track Mounting/Front Connecting Socket
P2CF-11
Terminal Arrangement/
Internal Connections
(T op V iew)
Surface Mounting Holes
Two, 4.5 dia. or two, M4
40±0.2
Two, 4.5 dia.
holes
Eleven,
M3.5 x 7.5 sems
70 max.
50 max.
31.2 max.
7.8
3 4.5
35.4
4
P2CF-11-E (Finger Safe Terminal Type)
Conforming to VDE0106/P100
Two, 4.5 dia.
holes
Eleven,
M3.5 x 7.5 sems
7.8
70 max.
4
40±0.2
50 max.
35.4
31.2 max.
30
5 4.5
3
1.2

Omron H3CR-A8 Specifications

General

Time Range	0.05 s to 300 h
Operating Temperature	-10 to 55°C
Terminal Type	Screw
Number of Pins	8
Contact Rating	5 A at 250 VAC
Storage Temperature	-25 to 65°C
Operating Voltage	100 to 240 VAC
Mounting Type	DIN Rail
Output Type	SPDT
Dimensions	48mm x 48mm
Operating Modes	Interval
